Low Rds(on): Low on-state resistance reduces
energy loss and heat generation, improves
battery efficiency, and extends range.
Excellent Thermal Characteristics and Heat Dissipation
Capability: Effective heat dissipation capability ensures
stable operation under high loads, prolonging the lifespan of the electric bicycle system.
Product
Power MOSFET Solution
| Part Number | Status | Package | Tj max (°C) | Qualification | Configuration | Type | ESD Protect | VDS (V) | VGS(±V) | ID (A) | PD (W) | Ron@10V(mΩ) | Ron@4.5V(mΩ) | Ron@2.5V(mΩ) | Ron@1.8V(mΩ) | VGS(th)(typV) | VGS(th)(maxV) | Ciss(pF) | Coss(pF) | Crss(pF) | Qg*(nC)@4.5V | Qg*(nC)@10V | Qgs(nC) | Qgd(nC) | Trr(ns) | Qrr(nC) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SOT-23 | 150 | Commercial | Single | N | NA | 150 | 20 | 0.76 | 1.1 | 880 | 940 | - | - | 1.8 | 2.5 | 222 | 7.6 | 3 | 3.1 | 6.4 | 0.98 | 0.97 | 18 | 9 | ||
| Common Part | TO-220 | 150 | Industrial | Single | N | NA | 150 | 20 | 12 | 2 | 250 | 275 | - | - | 2 | 3 | 718 | 19 | 7.8 | 6.3 | 13 | 1.86 | 2.41 | 30 | 15.1 | |
| Common Part | TO-251 | 150 | Industrial | Single | N | NA | 150 | 20 | 12 | 2.1 | 250 | 275 | - | - | 2 | 3 | 718 | 19 | 7.8 | 6.3 | 13 | 1.86 | 2.4 | 30 | 15.1 | |
| Common Part | TO-220F | 150 | Industrial | Single | N | NA | 100 | 20 | 46 | 22.7 | 10.7 | 15.5(6V) | - | - | 3 | 4 | 1558 | 523 | 55 | 19.9 | 30.1 | 8.8 | 9 | 50.8 | 40 | |
| Common Part | PDFN3.3x3.3 | 150 | Industrial | Single | N | NA | 100 | 20 | 49 | 36 | 9.2 | 14 | - | - | 2 | 3 | 1915 | 505 | 35 | 22.1 | 40 | 8.93 | 10.5 | 37.2 | 35.1 | |
| New | TO-252 | 150 | Industrial | Single | N | NA | 100 | 20 | 71 | 66 | 8.8 | 13.6 | - | - | 2 | 3 | 2113 | 580 | 38 | 22.5 | 43.3 | 8.2 | 10.8 | 45.5 | 51.2 | |
| Common Part | TO-251 | 150 | Industrial | Single | N | NA | 100 | 20 | 87 | 65.8 | 8.8 | 13 | - | - | 2 | 3 | 2115 | 580 | 38 | 22.5 | 43.3 | 8.2 | 10.8 | 45.8 | 51.2 | |
| Common Part | PDFN-56 | 150 | Industrial | Single | N | NA | 100 | 20 | 87 | 66 | 8.6 | - | - | - | 3 | 4 | 2053 | 710 | 45 | 23.4(6V) | 35.5 | 10.7 | 9.6 | 42.6 | 40.5 | |
| Common Part | TO-220 | 150 | Industrial | Single | N | NA | 100 | 20 | 91 | 78 | 8.5 | 13 | - | - | 2 | 3 | 2113 | 580 | 38 | 22.5 | 43.3 | 8.2 | 10.8 | 45.4 | 51.2 | |
| NRND | SOP-8 | 150 | Industrial | Single | N | NA | 100 | 20 | 10.7 | 1.7 | 8.4 | 13 | - | - | 2 | 3 | 1932 | 387 | 30 | 22.8 | 41.8 | 5.6 | 12.3 | 49 | 58.7 | |
| NRND | PDFN-56 | 150 | Industrial | Single | N | NA | 100 | 20 | 68 | 66 | 8.4 | 13 | - | - | 2 | 3 | 1930 | 387 | 30 | 22.8 | 41.7 | 5.5 | 12.3 | 48 | 78.3 | |
| Common Part | PDFN-56 | 150 | Industrial | Single | N | NA | 100 | 20 | 91 | 65.8 | 8 | 12.5 | - | - | 2 | 3 | 2111 | 579 | 38 | 22.5 | 43.3 | 8.1 | 10.8 | 45.5 | 51.1 | |
| Part Number | Status | Package | Tj max (°C) | Qualification | Configuration | Type | ESD Protect | VDS (V) | VGS(±V) | ID (A) | PD (W) | Ron@10V(mΩ) | Ron@4.5V(mΩ) | Ron@2.5V(mΩ) | Ron@1.8V(mΩ) | VGS(th)(typV) | VGS(th)(maxV) | Ciss(pF) | Coss(pF) | Crss(pF) | Qg*(nC)@4.5V | Qg*(nC)@10V | Qgs(nC) | Qgd(nC) | Trr(ns) | Qrr(nC) |
