Small signal MOSFETs deliver high power density in compact packages. Leadpower’s robust portfolio
of P-channel and N-channel small signal MOSFETs offer low on-resistance and a wide range of voltage and
package options with unquestionable reliability.
MOSFETs are versatile workhorses in power electronics.
When reliable switching, low on-resistance, and a compact footprint are needed, our portfolio provides the
performance and reliability required for industrial and automotive applications.
Product
Power MOSFET Solution
| Part Number | Status | Package | Tj max (°C) | Qualification | Configuration | Type | ESD Protect | VDS (V) | VGS(±V) | ID (A) | PD (W) | Ron@10V(mΩ) | Ron@4.5V(mΩ) | Ron@2.5V(mΩ) | Ron@1.8V(mΩ) | VGS(th)(typV) | VGS(th)(maxV) | Ciss(pF) | Coss(pF) | Crss(pF) | Qg*(nC)@4.5V | Qg*(nC)@10V | Qgs(nC) | Qgd(nC) | Trr(ns) | Qrr(nC) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SOT-23 | 150 | Commercial | Single | N | NA | 150 | 20 | 0.76 | 1.1 | 880 | 940 | - | - | 1.8 | 2.5 | 222 | 7.6 | 3 | 3.1 | 6.4 | 0.98 | 0.97 | 18 | 9 | ||
| Common Part | SOT-23 | 150 | Commercial | Single | N | YES | 60 | 20 | 0.31 | 0.36 | 1900 | 2200 | - | - | 1.6 | 2.5 | 26.2 | 2.7 | 1.7 | 0.9 | 1.7 | 0.4 | 0.3 | 7.4 | 2.3 | |
| Common Part | SOT-523 | 150 | Commercial | Single | N | YES | 60 | 20 | 0.31 | 0.36 | 1900 | 2200 | - | - | 1.6 | 2.5 | 26.5 | 2.7 | 1.7 | 0.9 | 1.7 | 0.4 | 0.3 | 7.5 | 2.3 | |
| Common Part | FBP1006 | 150 | Commercial | Single | N | YES | 60 | 20 | 0.4 | 0.7 | 1900 | 2200 | - | - | 1.6 | 2.5 | 26 | 2.7 | 1.7 | 0.9 | 1.7 | 0.4 | 0.3 | 7.4 | 2.3 | |
| Common Part | SOT-23 | 150 | Commercial | Single | N | YES | 50 | 20 | 0.31 | 0.36 | 1900 | 2200 | - | - | 1.2 | 1.5 | 25.2 | 3.2 | 2.1 | 0.9 | 1.7 | 0.3 | 0.3 | 7.2 | 1.9 | |
| SOT-23 | 150 | Industrial | Single | N | YES | 30 | 8 | -1.2 | 0.9 | - | 420 | 490 | 600 | -0.7 | -1.3 | 185 | 21 | 16 | 1.9 | - | 0.4 | 0.3 | 10 | 2.2 | ||
| Common Part | FBP1006 | 150 | Commercial | Single | N | YES | 30 | 12 | 1 | 0.69 | - | 420 | 565 | 850 | 0.95 | 1.3 | 350 | 435 | 740 | 0.85 | - | 0.29 | 0.16 | 24.1 | 3.2 | |
| Common Part | PDFN3.3x3.3 | 150 | Commercial | Single | N | NA | 30 | 20 | 38 | 23 | 10 | 13.8 | - | - | 1.6 | 2.1 | 875 | 112 | 100 | 10.2 | 20.4 | 2.5 | 4.8 | 25.2 | 10.4 | |
| PDFN3.3x3.3 | 150 | Commercial | Single | N | NA | 30 | 20 | 64 | 31 | 4.8 | 6.9 | - | - | 1.6 | 2.1 | 1859 | 260 | 212 | 26 | 48 | 3.4 | 14 | 18.2 | 9.2 | ||
| Common Part | SOT-563 | 150 | Commercial | Complementary | N+P | YES | 20 | 12 | 1 | 0.42 | - | 250 | 365 | 585 | 0.75 | 1 | 40 | 16.5 | 10.1 | 1 | - | 0.31 | 0.11 | 9 | 0.78 | |
| Common Part | SOT-23 | 150 | Commercial | Single | N | NA | 20 | 12 | 3.2 | 0.9 | - | 60 | 86 | - | 0.7 | 1 | 123 | 30 | 26 | 1.8 | 3 | 0.5 | 0.9 | 11.6 | 3.6 | |
| DFN2*3 | 150 | Commercial | Dual | N+N | YES | 20 | 12 | 7.5 | 0.98 | - | 8 | 11 | - | 0.75 | 1 | 1340 | 180 | 150 | 16.9 | - | 3.26 | 3.74 | - | - | ||
